Kystar KT4 Pro Theater-grade Splicing Processor

Kystar KT4 Pro Theater-Grade Splicing Processor display four windows of images on a single screen or control four different LED screens.

Categories: , Tags: ,

Description

Kystar Theater-grade Splicing Processor KT4 Pro brief introduction
01

Kystar KT4 Pro support four-channel DVI output synchronous splicing , the most load up to 10.4 million pixels. The maximum width is 16,000 pixels and the maximum is 8,000 pixels.

20200214110812

Display of Six Windows

02

KT Pro series processor can display six windows of  same or different input signals. The windows can be arranged across the outputs and be overlaid of each other. It can not only display multiple signals on a single LCD screen & LED screen, but also realize centralized control of multiple screens easily.

Multi-format Signal Processing

03

KT Pro series processor supports six channels of video signal input, including DP×1, HDMI×1, DVI×1, Pandora×1, and two channels of custom signal that can be configured as HDMI, DVI or SDI.

20200304112753-1
20200214115749-1

Visualized Operation

04

The front panel of KT Pro series processor  is equipped with a 4.3-inch true color monitor screen, which can monitor the spliced output image or input signal images in real time. It can realize the visualized operation, greatly increase the reliability of signal management.

20200304113618-1

Built-in Pandora Multimedia System

05

KT Pro series processor is equipped with Pandora multimedia system that supports the WIFI hotspot. Users can edit and manage multimedia files through Kommander PE or Pandora box app.

At the same time, users can manage the Kystar Theater-Grade Splicing Processor KT4 Pro processor via the Kares cloud-based system.

20200214120802-1

Wireless Casting

06

KT4 Pro series processor has built-in WIFI hotspot, which enables devices of Android, IOS, Windows to wirelessly cast display content on the screen.

Seamless Switching

07

KT4 Pro series processor supports fade-in and fade-out seamless switching of signals and presets, without blank or delay during the process.

20200303170455-1
20200218114117-1

Multi-machine cascade expansion

08

KT4 Pro series processor supports frame synchronization technology,multiple machines can be cascaded by using DVI-Loop interface to reach higher resolution.

20200304114026-1

Signal Hot Backup

09

KT series processor supports multi-level signal hot backup. It can designate any signal as the backup of the current signal. When the primary signal fails, the backup signal can be switched on automatically.

20200925111027-1024x452-1

KT4, KT4Pro, KT6 Parameters Difference
