Huidu HD-A6 Dual-mode LED Display Player

Huidu HD-A6 is the second generation Dual-mode LED display player, supports asynchronous playback, synchronous playback, U-disk socket and video auto-scaling functions, with the maximum load capacity 2.3 million pixels. Come with Wi-Fi module, support mobile APP management. Equipped with 8GB memory, support expending memory by U-disk. Support optional 4G module, remote cluster control.

Description

Huidu HD-A6 is the second generation Dual-mode LED display player, supports asynchronous playback, synchronous playback, U-disk socket and video auto-scaling functions, with the maximum load capacity 2.3 million pixels.
Come with Wi-Fi module, support mobile APP management. Equipped with 8GB memory, support expending memory by U-disk. Support optional 4G module, remote cluster control.

Dual-mode LED Display Player HD-A6 Features:

1. Support asynchronous and synchronous swithing using.
2. HDMI HD video zoom, no need video processor.
3. 8GB memory, expending memory by U-disk.
4. Come with Wi-Fi, mobile APP wireless management.

Dual-mode LED Display Player HD-A6 Parameters:

Function Parameters
Control Range Resolution:   2.3   million pixels (1920*1200), Widest 16384 pixel, highest 4096 pixel
Gray Scale 256-65536 (adjustable)
Basic Functions Video, Pictures, Gif, Text, Office, Clocks, Timing,   etc.

Remote, Temperature, Humidity, Brightness, PM Value,   etc.

Support Synchronized picture auto-zooming, Playing   live screen without video processor.

Video Format HD video hard   decoding, 60Hz frame rate output.

AVI, WMV,   RMVB, MP4, 3GP, ASF, MPG, FLV, F4V, MKV, MOV, DAT, VOB, TRP, TS, WEBM, etc.

Image Format Support   BMP, GIF, JPG, JPEG, PNG, PBM, PGM, PPM, XPM, XBM, etc.
Text Text editing, Image,   Word, Txt, Rtf, Html, etc.
Document DOC,   DOCX, XLSX, XLS, PPT, PPTX, etc.

Office2007 Document format

Time Classic Analog   Clock, digital clock and various of clock with image background
Audio output Double track   stereo audio output
Memory 8GB Flash Memory, Expanding memory by U-disk
Communication 100M/1000M RJ45 Ethernet, Wi-Fi, 3G/4G, LAN, USB
Working Temp -40℃-80℃
Port IN:12V Power Adapter*1, 1Gbps RJ45*1, USB 2.0*1, Test Button*1, GPS, 3G/4G(Optional), Sensor port*1, HDMI*1

OUT:1Gbps RJ45*1,AUDIO*1,HDMI*1

Power 18W (12V DC power supply)

Dual-mode LED Display Player HD-A6 Method:

  1. Internet unified management: The play box can be connected to the Internet through 3G/4G (optional), network cable connection, or Wi-Fi Bridge.

5e2fff141a4da4b78d7d9d38697c3273

  1. Asynchronous one-to-one control: Update programs by network cable connections, Wi-Fi connections or USB flash drives. LAN (cluster) control can access the LAN network through by network cable connection or Wi-Fi Bridge.

7370f7a11bb19621a937e09c7cb44d66

  1. Real-time picture synchronization display: The play box is connected to the sync source through the HDMI high-definition video line, and the sync picture is automatically scaled without any setting.

241a0fa57b74ab5678a4c92449c096c0
Super LED Controller HD-A6 Control Video:
